PL-15 Missile

PL-15 Missile Latest News

Amid the ongoing escalating tensions between India and Pakistan, a fully intact Chinese-made PL-15 long-range air-to-air missile has been recovered in Punjab’s Hoshiarpur.

About PL-15 Missile

• The PL-15, known as “Thunderbolt-15,” is a long-range, beyond-visual-range air-to-air missile (BVRAAM).
• It was developed by China’s 607 Institute and manufactured by the China Aerospace Science and Industry Corporation (CASIC).
• It can engage enemy aircraft at distances well beyond visual range.

‹ ›

PL-15 Missile Features

• It features a dual-pulse solid-propellant rocket motor, allowing it to reach speeds exceeding Mach 5.
• The domestic Chinese version boasts a range of 200–300 km, while the export variant, the PL-15E, has a declared maximum range of 145 km, though operational factors may reduce this to 100–120 km depending on the launch platform.
• The missile is equipped with a high-explosive fragmentation warhead weighing 20–25 kg, optimized to destroy maneuvering aerial targets.
• The PL-15 employs a sophisticated guidance system, combining inertial navigation, Beidou satellite updates, a two-way datalink for mid-course corrections, and a terminal active radar seeker using advanced AESA (Active Electronically Scanned Array) technology.
• This suite provides high accuracy, resistance to electronic jamming, and the ability to engage targets in contested environments.

PL-15 Missile FAQs

Q1: What is the range of the PL-15 missile?

Ans: The domestic Chinese version boasts a range of 200–300 km, while the export variant, the PL-15E, has a declared maximum range of 145 km.

Q2: What is the top speed of PL-15?

Ans: The PL-15 features a dual-pulse solid-propellant rocket motor, allowing it to reach speeds exceeding Mach 5

Q3: What type of missile is the PL-15?

Ans: Beyond-Visual-Range Air-to-Air Missile (BVRAAM

Source: INDIATV
